    HYUNDAI

    WL1-0169

    Turbo Parts No 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Turbo Model TD025
    OEM Part 28231-27500 28231-27500 2823127500 49173-02622 49173-02620 49173-02612 49173-02610
    Application Model Hyundai Getz 1.5 CRDi Build: Jan 2003 to Dez 2008 Engine: D3EA Capacity: 1493 ccm Power: 60 Kw
    Engine Code D3EA
    Turbocharger
    WL1-0169
    Fit for: 49173-02610/28231-2750049173-02612/49173-02620/49173-02622 Hyundai Lavita / VerNA/ Click TD025 28231-27500 28231-27500 2823127500 49173-02622 49173-02620 49173-02612 49173-02610
    €EU 150.88
    €EU 137.16
    BUY NOW
    ADD TO CART
    Item Welot Code Turbo Parts No.
    CHRA/ Core Assembly WL2-0382 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Electronic Actuator / 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    VNT Nozzle Ring / 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Turbine Housing WL3-1883 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Compressor Housing WL3-0564 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Bearing Housing WL3-0412 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Compressor Wheel WL3-0734 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Heat shield WL3-1074 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Shaft & Wheel WL3-1657 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Seal plate WL3-1487 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Back plate / 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Oil Pipe WL3-0955 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Repair Kits WL3-1309 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Gasket Kits WL3-0955 49173-02610/28231-2750049173-02612/49173-02620/49173-02622
    Calibration Data
    VSR Balance Calibration /
    T/hsg Angle /
    C/hsg Angle /
    Actuator Calibration 1 /
    Actuator Calibration 2 /
    Actuator Calibration 3 /
    Welot Code WL3-0412
    Turbo Parts No 49173-07503/49173-07508/49173-07502/49173-07504/49173-07506/49173-07507//28231-27500
    A Dia 56
    B Dia 43.97
    C Oil Inlet M10*1
    D Oil Outlet 2-M6*1
    H Water 69.75
    VNT Lever Position N/a
    Welot Code WL3-1657
    Turbo Parts No 49173-06501/49173-02610/28231-27000/28231-27500
    A Dia 36.8
    B Dia 31.5
    C Dia 5.6
    D Dia 6
    E Dia 4
    Blades 12
    Closed or Open Closed
    QTY of Rings 1
    Remark /
    Welot Code WL3-0734
    Turbo Parts No 49173-07503/49173-07508/49173-07504/49173-07506/49173-07507/49173-07502/49173-02610/28231-27500
    Inducer Diameter A 29
    Exducer Diameter B 40
    Shaft Bore C 4
    Tip Height D 4.1
    Total Height E 18
    Blades 6/6
    Flatback / Superback Flatback
    Milling Wheel /
    Remark /
    Welot Code WL3-1487
    Turbo Parts No 49173-07503/49173-07508/49173-07504/49173-07506/49173-07507/49173-07502/49173-02610/49173-06501
    A Dia N/a
    B Dia 40
    C Dia 8
    D Height 10.8
